4.2 × 16mm Wafer Head Self-Drilling Framing Screws – Box of 1000
4.2 × 16mm Wafer Head Self-Drilling Screws are zinc-finished carbon-steel fixings designed for joining thin metal sections within drywall framing, ceiling-track and general light-gauge metal constructions.
The integrated drill point penetrates compatible sheet steel and forms the fixing hole as the screw is driven. This allows suitable metal framing sections to be joined without completing a separate drilling operation first.
Each screw has a fixed specification:
- 4.2mm nominal thread diameter
- 16mm overall length
- Low-profile wafer head
- Phillips PH2 drive
- Self-drilling point
- Self-tapping thread
- Carbon-steel construction
- Zinc finish
- Maximum drilling thickness of 3mm
For Drywall Track and Metal Framing
The screws are intended for stitching compatible light-gauge metal components together during the construction of drywall and suspended-ceiling systems.
Typical applications include:
- Joining metal studs to tracks
- Connecting overlapping track sections
- Securing ceiling-track components
- Joining light-gauge steel framing sections
- Fixing compatible brackets and thin metal accessories
- General thin sheet-metal assembly
They are not standard plasterboard screws. Plasterboard sheets normally require the bugle-head drywall screws specified for the board thickness, framing gauge and complete wall or ceiling system.
Self-Drilling Point
The formed drill point cuts through compatible thin sheet metal before the thread engages with the material.
This combined drilling and fixing action helps:
- Remove the need for a separate pilot-hole operation in supported steel thicknesses
- Reduce the number of tools required during framing work
- Speed up repetitive metal-to-metal connections
- Maintain alignment between overlapping framing components
- Create a secure threaded connection in one operation
The verified maximum drilling thickness is 3mm. This limit applies to the combined steel thickness encountered by the drill point and must not be exceeded.
Self-Tapping Thread
After the point has drilled through the metal, the self-tapping thread forms and engages its mating thread within the steel.
The screw must be driven at a suitable speed and kept square to the fixing surface so that the drill point cuts cleanly before the thread begins to pull the components together.
Do not describe the thread as a fine drywall-board thread. Its purpose is to join thin metal framing components rather than secure a gypsum board face.
Low-Profile Wafer Head
The broad wafer head provides a large bearing surface while maintaining a relatively low installed profile.
This helps:
- Clamp two thin metal sections together
- Spread the fixing load over a larger area
- Reduce the likelihood of the head pulling through thin sheet material
- Limit projections from the face of the framing
- Create a neat connection between overlapping sections
The wafer head remains visible above the metal surface. It does not countersink into the substrate.
Phillips PH2 Drive
The screw uses a Phillips No. 2 recess and is supplied with one compatible PH2 S2 driver bit per box.
A correctly fitting PH2 bit helps:
- Transfer drilling and driving torque effectively
- Keep the tool aligned with the screw
- Reduce slipping from the drive recess
- Provide consistent installation during repetitive framing work
Replace the supplied bit when it becomes worn or begins slipping repeatedly.
Zinc-Finished Carbon Steel
The screws are manufactured from carbon steel and finished with zinc for use in clean, dry internal construction environments.
The zinc finish provides limited corrosion protection during storage and normal internal service. It is not an exterior-grade coating and should not be treated as suitable for exposed or persistently damp conditions.
Do not use these screws where they will be subjected to:
- Direct external weather exposure
- Persistent condensation
- Continuously damp construction
- Marine or salt-laden environments
- Aggressive chemicals
- Applications requiring stainless steel or a specialist exterior coating
Internal Drywall Construction
The screws are suited to internal drywall-track and ceiling-track construction where the framing remains within a clean, dry building environment.
Where light-gauge metal framing is used externally or within a higher-corrosion environment, select a fixing with an appropriate exterior corrosion rating.
Fire and Acoustic Systems
The screw does not independently provide a fire-resistance period or acoustic rating.
Where used within a fire-rated or sound-insulating construction, performance belongs to the complete tested or assessed system, including:
- The stud and track specification
- The framing gauge and centres
- The board type and number of layers
- The insulation
- The framing and board fixings
- The joints and perimeter treatment
- Service penetrations and openings
Use the screw only at the locations permitted by the system specification.
Key Benefits
- 4.2 × 16mm metal-framing screw
- Self-drilling point removes a separate pilot-hole stage
- Suitable for combined steel thicknesses up to 3mm
- Self-tapping thread forms a secure metal connection
- Broad wafer head provides effective clamping
- Low-profile head limits projection from the framing
- PH2 recess supports positive driving
- Zinc-finished carbon-steel construction
- Supplied in a box of 1,000
- One PH2 S2 driver bit included
4.2 × 16mm Self-Drilling Screws Technical Specifications
| Product Name |
4.2 × 16mm Wafer Head Self-Drilling Framing Screws |
| Matched Manufacturer |
TIMCO |
| Product Code |
00016WHSD |
| Product Type |
Metal-construction sheet and framing screw |
| Nominal Diameter |
4.2mm |
| Length |
16mm |
| Head Type |
Wafer head |
| Drive Type |
Phillips |
| Driver Size |
PH2 |
| Point Type |
Self-drilling |
| Thread Type |
Self-tapping |
| Material |
Carbon steel |
| Finish |
Zinc |
| Maximum Drilling Thickness |
3mm combined compatible sheet steel |
| Primary Substrates |
Thin sheet metal and drywall framing |
| Primary Application |
Stitching drywall track, ceiling track and compatible light-gauge metal framing components |
| Pack Quantity |
1,000 screws |
| Driver Bit Included? |
Yes, one PH2 S2 bit |
| Corrosion Rating |
Rating 1: clean, dry and low-humidity environments |
| CE Standard |
BS EN 14566:2008 and BS EN 10666:2008 |
| Reaction-to-Fire Classification |
A1 |
| Suitable for Exposed External Use? |
No |
| Plasterboard Sheet Fixing? |
No; use the specified bugle-head drywall screw for fixing plasterboard sheets |
| Standalone Fire Resistance? |
No |
| Standalone Acoustic Rating? |
No |
Product Setup
| Size |
Head |
Drive |
Pack Quantity |
Product Code |
| 4.2 × 16mm |
Wafer |
PH2 |
1000 |
00016WHSD |
Variation Summary
| Diameter Options |
Length Options |
Pack Options |
Total Variations |
| 4.2mm |
16mm |
Box of 1000 |
1 |
Package Contents
- 1,000 × 4.2 × 16mm wafer-head self-drilling screws
- 1 × PH2 S2 driver bit
Not Included
- Drill-driver or screw gun
- Metal studs or tracks
- Plasterboard sheets
- Plasterboard fixing screws
- Exterior-grade corrosion protection
Storage
- Store in the original box in clean, dry conditions.
- Protect the screws from rain, condensation and high humidity.
- Do not install screws showing significant corrosion.
- Keep the drill points and PH2 recesses free from contamination.
- Do not mix the screws with sharp-point or exterior-coated variants.
How to Install 4.2 × 16mm Self-Drilling Framing Screws
Use these screws to join compatible thin metal framing components in accordance with the drywall or ceiling-system specification.
1. Verify the Fixing Application
Before installation, confirm that:
- The connection is metal to metal.
- The screw is required for joining studs, tracks or compatible framing accessories.
- The combined steel thickness does not exceed 3mm.
- The complete construction permits a wafer-head framing screw.
- The installation is within a clean, dry internal environment.
Do not use the screw as a substitute for the specified plasterboard fixing.
2. Inspect the Metal Framing
Check that the framing sections are:
- Correctly positioned and aligned
- Free from severe corrosion
- Securely supported
- Within the screw’s drilling capacity
- Free from concealed cables or services at the fixing point
3. Bring the Components Together
Hold or clamp the overlapping metal sections firmly in their final position.
Gaps between the components can allow the drill point to push one section away before the thread engages. Both pieces should remain in contact during drilling.
4. Fit the PH2 Driver Bit
Insert the supplied PH2 S2 bit into a suitable variable-speed drill-driver or screw gun.
Check that the bit fits fully into the Phillips recess. Replace it if it is worn or repeatedly slips from the screw head.
5. Position the Screw
Place the self-drilling point square to the metal surface at the specified fixing position.
Avoid fixing:
- Too close to an unsupported metal edge
- Through damaged or distorted framing
- Where the screw could contact electrical cables or pipework
- Through resilient or isolation components unless required by the system
6. Begin Drilling
Apply firm axial pressure and start the driver at a controlled speed.
Keep the screw perpendicular to the surface while the drill point cuts through the first and second metal layers.
Do not immediately operate the driver at uncontrolled maximum speed, as this can cause the point to skate across the surface or overheat before drilling through.
7. Allow the Thread to Engage
Once the drill point has penetrated the metal, continue driving so that the self-tapping thread forms and engages within the steel.
The screw should begin pulling the framing sections tightly together.
Stop and investigate where:
- The point fails to penetrate.
- The screw spins without tightening.
- The head recess begins to strip.
- The framing becomes distorted.
- The screw bends or enters at an angle.
8. Seat the Wafer Head
Stop when the underside of the wafer head is firmly seated against the metal surface.
The head should clamp the components together without crushing, tearing or excessively deforming the framing.
Do not continue driving once the screw is secure. Overtightening can strip the thread formed within thin steel and reduce the holding capacity.
9. Check the Connection
Confirm that:
- The screw is straight.
- The wafer head lies flat against the framing.
- The joined sections are held tightly together.
- The screw does not spin freely.
- The fixing has not distorted the stud or track.
- The head will not interfere with the next stage of construction.
10. Continue at the Specified Fixing Positions
Install the remaining screws according to the framing or drywall-system instructions.
Do not add unnecessary fixings through resilient or deflection details where the system requires movement.
11. Install the Plasterboard Separately
Once the metal frame is complete, secure the plasterboard using the board screw specified for:
- The board thickness
- The number of board layers
- The metal gauge
- The required fire or acoustic system
- The permitted screw centres
Do not use the 16mm wafer-head framing screws to attach the plasterboard face.
Use in Fire-Rated Systems
Follow the exact tested or assessed framing arrangement where the partition or ceiling requires a stated fire-resistance period.
The number and position of framing screws, board fixings, joints, tracks and deflection details must match the system specification.
Use in Acoustic Systems
Avoid installing screws that bridge isolation components or make unintended contact between separated framing elements.
An incorrectly positioned metal fixing can create a rigid path through an otherwise decoupled acoustic construction.
Final Inspection
Before boarding over the frame, verify that:
- All framing connections are secure.
- No screw is loose or stripped.
- No sharp drill point presents an avoidable service hazard.
- The framing remains plumb, level and correctly aligned.
- Movement and deflection details remain free to operate.
- The installation follows the specified drywall or ceiling system.
Important Environmental Note
The zinc-finished screws are intended for clean, dry and low-humidity internal environments.
Use an appropriately classified exterior or corrosion-resistant screw for exposed, damp or corrosive installations.
